Desun Optical Dissolved Oxygen Sensor Pond RS485 Water Quality Monitoring Sensor

Name: Desun Optical Dissolved Oxygen Sensor Pond RS485 Water Quality Monitoring Sensor
Brand: Desun Uniwill
Price: 260.00 USD

Desun Optical Dissolved Oxygen Sensor Pond RS485 Water Quality Monitoring Sensor Manufactures

Brand Name : Desun Uniwill

Model Number : DS-380

Place of Origin : China

MOQ : 0~100 pcs

Price : $260.00 - $380.00/ Piece

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 0~1000 pcs

Delivery Time : 7~ 15 working days

Packaging Details : Carton packaging

Principle : Optical method

Measuring range : 0~20mg/L or 0-200% saturation

Response time : 3 seconds

Accuracy : 1%

Protection level : IP68

Temperature range : 0~50°C

Temperature accuracy : ±0.2°C

Output : RS-485, MODBUS protocol

Power supply : DC 6~12V, current <50mA

cable length : Default 5 m

Housing material : SS316/Titanium alloy

Contact Now

Online Optical Dissolved Oxygen Detector probe Pond DO Water Quality Monitoring

Main Features

Ø The sensor adopts new type of oxygen sensitive membrane,with NTC temperature compensated function,whose measurement result has good repeatability and stability.

Ø Won't produce oxygen consumption when measuring and no requirement of flow rate and stirring.

Ø Breakthrough fluorescence technology,without membrane and the electrolyte and almost not need maintenance.

Ø Built-in self-diagnosis function to ensure the accuracy of data.

Ø Factory calibration,not need calibration for a year and can carry out field calibration.

Digital sensor,high anti-jamming capacity and far transmission distance.

Standard digital signal output,can achieve integration and networking with other equipment without controller.

Ø Plug-and-play sensor,quick and easy installation.

Item	Parameters
Model	DS380
Principle	Fluorescence analysis method
Measuring range	0~20mg/L or 0-200% saturation
Response time	3 sec
Accuracy	1%
Protection level	IP68
Installation	Submersible
Temperature sensor	NTC
Temperature range	0~50°C
Temperature accuracy	±0.2°C
Output	Support RS-485, MODBUS protocol
Power supply	DC 6~12V, current <50mA
Size	Φ26*155 mm
Probe cable length	Default 5 m, customized 10m, 15 m and 30 m cable
Fluorescent cap life	1 year
Maximum working pressure	3bar
Housing material	SS316/Titanium alloy

FAQ

Q: Is your company a manufacturer?

A: Yes,we are a professional manufacturer of online water quality monitoring products: oil in water sensor/ DO sensor/ NH4-N sensor / ORP / COD sensor / Blue-green algae sensor /Conductivity sensor /TDS / TSS /MLSS,ect.

Q: What parameters do you need for product selection?

A: Application, Range, Power supply and Output signal.

Q: What are your terms of payment and delivery time?

A: We could accept T/T, Paypal, Western Union, Credit Assurance. Generally, we will arrange the shipment within 7 days after received payment.

Q: How about warranty?

A: 12 months warranty
